Product dimenttions:

Model	Image	antenna size	Die-cut size	vertical gap(antenna)	Lateral gop(antenna)	Inaly roil width
LIJIA		76*45mm	85.5*54mm(5*5)
INLAY		76*45mm	85.5*54mm
SC-M001		45*76mm	54*85.5mm	13mm	29mm	74mm
SC-M002		15*52mm	18*56mm	10mm	32mm	47mm
SC-M003		diameter:22mm	diameter:25mm	8mm	25mm	47mm
SC-M004		22*35mm	25*38mm 25*40mm	8mm	25mm	47mm
SC-I002		45*45mm	50*50mm	8mm	12mm	57mm
SC-M007		32*32mm	35*35mm	8mm	15mm	47mm
SC-M008		11*26mm	15*30mm	20mm	21mm	47mm
SC-M009		diameter: 25mm	diameter: 28/30mm	15mm	22mm	47mm
SC-M010		diameter: 25mm	diameter: 30/35/40/45 mm
LJM-001		45*76mm	85.5*54mm	13mm	29mm	74mm

Electrical specifications
IC：        Mifare S50
Frequency： 13.56MHz
Protocol：  ISO 14443
Memory：    1K byte
Delivery information
Surface Material：  Paper or PET
Inner Core Size:   76mm
Quantity per roll: 1000~5000pcs(dry inlay)
1000~4000pcs(wet inlay/label)
Unwinding:         Chip side up
Quality:           100%tested,NG replaced
Environment
Operation:         -40℃ to 85℃
Storage:           -5℃  to 30℃
Data Retention:    100,000 cycles
